  • OTCS900 Cube Ice Maker


    OMT Cube Ice Maker has been adopted LED touch Screen,which can adapt the ice thickness easily,and the
    so the ice is very clean and safe for health.


    OMT 900kg Cube Ice Maker Technical Parameter:


    Model NumberOTCS900
    Ice ShapeCube Ice/Square Ice
    Ice Size22*22*22MM/29*29*22MM
    Machine Capacity900KG
    Ice Bin 470KG
    Cube Ice Grip Quantity13*18*2
    Cooling WayAir Cooled
    Refrigerant(Gas)R22/R404A/R134A
    Power2500W
    Machine Dimension1230*950*1850MM
    Machine Weight174.1KG
    Electricity Connection220V, 50Hz/60Hz, 1P
    380V, 50Hz/60Hz, 3P
    MaterialStainless Steel
    Lead Time35-40 Days
    Warranty12 Months


    OMT Cube Ice Maker Features:

    1)Small design, space-saving and easy to transport.



    2)Strong and durable.

     All our machine adopts world famous brand components, strict process control, low failure rate and long service life.



    3)Environmental refrigerant.
    The machine adopts freon–free R134A/R404A refrigerant, which is a new healthy ice-making mode.



    4)Santary, clean and edible Ice.

    The frame and outer shell plate adopts stainless steel ,and ice molds adopts Nickel-plated material, which make the ice reaches international standard for hygiene.


    OMT 900kg Cube Ice Maker Pictures :

    Machine Front View
    Machine Side View
    Machine UnitIce Storage Bin
    Ice Molds Front ViewIce Molds Back View


    OMT Cube Ice Maker Series:

    ItemCapacity
    (KG/24HRS)
    Power
    (W)
    Ice Bin
    (KG)
    Machine Dimension
    (MM)
    Machine Weight
    (KG)
    OTCS20201906350*455*56525
    OTCS404038015500*460*79035.1
    OTCS606042020500*590*79042.3
    OTCS808046040660*670*87058
    OTCS10010062040660*670*87058.2
    OTCS12012070040660*670*87058.2
    OTCS180180800145580*825*158074.5
    OTCS250250950210780*825*1650110
    OTCS3003001250280780*860*175097.7
    OTCS4004001650280780*825*1830118.5
    OTCS5005002200280780*825*1830128.5
    OTCS70070025004701230*950*1850174.1
    OTCS90090037004701230*950*2050240
    OTCS1000100045007001250*930*1930350
    OTCS1500150070007001230*1240*2000350

    ⊙ Refrigerant:R22/ R404A/R134A
    ⊙ Supply Power:220V, 60Hz, 3Phase; 380V, 60Hz, 3Phase; 440V, 60Hz, 3Phase;
    ⊙ Working Conditions: Input Water Temp: 21℃; Ambient Temp: 25℃; Evaporator Temp: -20℃; Condensing Temp: 40℃
    ⊙ Model and specifications can be changed without notice.



    Machine Configuration List:

    Main partsBrandOriginal country
    CompressorEmbraco/DanfossEuropean/Denmark
    Expansion ValveDanfossDenmark
    Dry filterDanfossDenmark
    Electromagnetic ValveSaginomiyaJapan
    Cooling fanEBMGermany
    Water pumpEBM/NewdunmotorsGermany/China
    Control boardOMTChina, Time control board
    Stainless steel sheet0.8mm thicknessChina
    RefrigerantR22/R404aUSA
    LED touch ScreenIce thickness adjust from outside LED touch screen
