  • DOTB50 Fast Freezing Block Ice Making Machine


    The container used for containerized block ice machine is international 20 feet
    standard container.In a 20 feet container, the maximum daily capacity is 3 tons and the maximum height of block ice is 700mm.

    OMT 5ton Fast Freezing Block Ice Making Machine Technical Parameters:

    Model NumberDOTB50
    Machine Capacity5000kg/24 hours
    Weight of Ice Block25kg/pcs (available for 5kg, 20kg etc.)
    Ice Block Size280*155*700mm
    MaterialIce MoldAluminun Plate, corrosion free
    Mainframe Stainless Steel 304
    Ice Freezing Time52blocks/300mins
    RefrigerantR22 or R404a
    Cooling WayWater cooled(Air cooled)
    Compressor25HP, Brand: Bitzer/Germany
    Supply Power220V~480V, 50Hz/60Hz, 3P
    Machine Power20.8KW
    Machinery Dimensions5840*2000*2050(H)mm
    Ice Harvest WayManual Forklift
    Warranty12 months

    OMT Fast Freezing Block Ice Making Machine Features:

    1. Edible Ice.
    Evaporated directly without using chemical and salt water, the ice is clean and can be eaten directly.

    2. Fast freezing time.
    You can get 5kg ice in 140minutes and 3-3.5hrs for 10kg ice, much faster than salt water type ice block machine.

    3. High Quality Material.
    Ice moulds are made of aluminum plate, mainframe adopts anti-rust and anti-corrosion material--stainless steel.

    4. Compact design and saves space.

    5. Simple to operate and no need skilled worker.

    OMT 5ton Fast Freezing Block Ice Making Machine Pictures:

    Machine Front ViewMachine Back View


    Clean and Edible Ice, Fast Freezing TimeClean and Edible with Fins, Fast Freezing Time

    OMT Fast Freezing Block Ice Making Machine Series:

    Item Capacity (Ton/24hours)Compressor Power(HP)Dimension (L*W*H) (mm)Cooling Way
    DOTB10161800*1100*1200Air Cooled
    DOTB202104260*900*1950Air Cooled
    DOTB303153976*1468*2095Air Cooled
    DOTB505254660*1712*2180Water Cooled
    DOTB606305236*1790*2095Water Cooled
    DOTB10010603300*1800*2250Water Cooled
    DOTB2002035*32800*1500*2200Water Cooled

    ⊙ Refrigerant: R22 or R404a
    ⊙ Supply Power: 220V~480V, 50Hz/60Hz, 3P;
    ⊙ Standard Working Conditions: Input water temp: 21℃; Ambient temp: 25℃; Condensing temp: 40℃;
    ⊙ Model and specifications can be subject to change without notice.



    Machine Configuration List:

    Component ItemBrand and Origin
    Compressor Copeland/Bitzer
    PLC controller

    Siemens/ Germany

    Oil separator  EMERSON/ USA
    Electrical componentsLG (LS)/South Korea
    Solenoid valve  CASTAL/Italy
    High pressure controllerDANFASS/ Denmark
    Low pressure controllerDANFASS/ Denmark
    Expansion valveCASTAL/Italy
